1、 Precautions for dismantling the silver linear guide rail:
1) There are plastic parts at the end and side of the upper silver linear guide slide. Please do not use hard rocket tools to hammer during installation. During trial operation after installation, do not let any object collide with it when it exceeds the speed limit. If the plastic parts break, the ball will roll out and the slide will also fall.
2) Before leaving the factory, the upper silver linear guide rail had lubricating oil stored at one place. If it needs to be cleaned, it should be dried first and the lubricating oil should be stored at home. It is strictly prohibited for the upper silver linear guide rail to run without lubrication
3) If it is not necessary, do not remove the slider from the upper silver linear guide rail. If it is not necessary, make sure to align the auxiliary upper silver linear guide rail first, and then remove the slider
4) It is strictly prohibited to dismantle various components of the silver linear guide rail at will, as one side may affect accuracy and flexibility. It is strictly prohibited to add non compliant rolling balls to the silver linear guide rail at will
&Nbsp
2、 Points to pay attention to when installing the silver linear guide rail:
1) When calibrating the level of the machine, two equal height measuring blocks and a marble measuring ruler should be placed on the installation surface, and a precise level gauge should be placed to adjust the level of the base. The requirement is that the base is convex in the middle (2-3 grids)
2) The roughness of the installation base surface of the upper silver linear guide rail must be measured using a laser interferometer after horizontal adjustment. The flatness of the installation base surface of the main upper silver linear guide rail is allowed to protrude 0) 05mm every 10m, and the straightness of the entire stroke must be measured. Roughness requirement 1) 6, with no casting defects on the appearance
3) When chamfering the installation base surface of the silver linear guide rail and the reference installation surface on the guide rail side, the chamfering radius should be less than or equal to 3) 5mm
4) The machining of the locking threaded hole on the installation base of the silver linear guide rail needs to confirm whether the position of the installation screw hole is correct, and the center distance between each connected screw hole 120mm is greater than 0) 1mm or less than 0) 1mm; To ensure high-precision screw hole processing, it is required to use CNC equipment for positioning processing
5) After unpacking, check whether the silver linear guide rail has a certificate of conformity, is there any damage or rust, and clean the rust preventive oil to remove burrs, bumps, and dirt on the assembly surface
